Pentair Southern Cross End Suction ISO Pro

PENTAIR SOUTHERCROSS ISO Pro

Designed and manufactured to the highest quality meeting the requirement of reliability and longevity in the most demanding applications.

FEATURES

• Heavy duty oil lubricated taper roller bearings
• Australian designed and manufactured
• Superior hydraulic design & manufacturing methods produce significantly higher efficiencies for lower running costs and reduced maintenance
• Australia wide backup
• Heads to 160 metres
• Up to 250 litres per second discharge
• Manufactured to ISO 5199 Standard
• Heavy duty design type 316 shaft
• High strength cast iron bearing housing
• Mechanical seals fitted as standard with single on-shaft mechanical seal
• Superior hydraulic design and manufacturing processes, together with double curvature impeller blades, provide highly efficient suction performance, higher speed capabilities and greater performance for reduced running costs and maintenance.
• 1600kPa pressure rating
• Taper mounted impeller for positive drive and easy removal
• Replaceable stainless steel or zinc free bronze wear rings
• Reusable ‘O’ ring body seals in Viton as standard and Teflon or EPDM as options
• AS2129 Flanges
• Standard tappings —Volute drain plug, suction flange tapping for suction gauge and discharge flange tapping for pressure gauge
