GPA Horizontal Split Case GSC Series

GPA GSC Series

FEATURES

• Axially split case design allows the easy removal of the top casing for services
• High efficient impeller design guarantees lower energy cost and longer service life
• It can be horizontal or vertical mounted
• A wide range of performance with head up to 200m
• Suction and discharge flange can be in conformity with ANSI or PN standard
• Maximum pumping temperature of 130°C
• Application: Water Supply, Hot & Cold Water Circulation, Fire Fighting, Air Conditioning, Raw Water Supply, Drainage, General Industry, Power Plant

SPECIFICATION

• Model: GSC / GSC-V
• Pumping Medium: Clean Water, Industrial Water
• Temperatures: ≤ 105 °C
• Materials:
  • Casing: Standard - Cast Iron; Optional - Ductile Cast Iron, Stainless Steel 304, 316, Duplex Stainless Steel
  • Impeller: Standard - Bronze; Optional - Cast Iron, Ductile Cast Iron, Stainless Steel 304, 316, Duplex Stainless Steel
  • Shaft: Standard - Carbon Steel; Optional - Stainless Steel 420, Duplex Stainless Steel
  • Shaft Sleeve: Standard - Stainless Steel; Optional - Stainless Steel
  • Case Wear Ring: Standard - Bronze; Optional - Cast Iron, Ductile Cast Iron, Stainless Steel 304, 316, Duplex Stainless Steel
  • Impeller Wear Ring: Standard - Bronze; Optional - Cast Iron, Ductile Cast Iron, Stainless Steel 304, 316, Duplex Stainless SteelMechanical Seal: Standard - Carbon/Ceramic; Optional - SiC/SiC or Tungsten Carbide/Tungsten Carbide
  • Ball Bearing: Steel
