Roto Progressive Cavity Screw Pump DM Series

ROTO DM Series

DM series pumps are specially designed for applications in food, beverage and cosmetic industries. The pumps are simple in construction with emphasis on quick cleaning. All metallic parts in contact with the media are 316 and 304 stainless steel with smooth finish. Wide throat hopper inlets incorporating coupling rod mounted augers are available for highly viscous media.

DESIGN, FEATURES AND BENEFITS

• POSITIVE DISPLACEMENT - The head developed is independent of speed whereas capacity is proportionate to the speed
• NON-CONTAMINATING METALS - All metallic surfaces in contact with the media are smooth surface stainless steel
• NO RETAINING POCKETS - Avoids chemical or bacterial contamination
• CLEANING IN PLACE - Ensures positive cleaning
• HIGH SUCTION LIFT - Ideal for lifting viscous fluids. Effective even in the high vacuum conditions
• LOW FLUID VELOCITY - Ensures gentle handling of shear sensitive fluids
• UNIFORM FLOW - No pulsation, turbulence or aeration
• NON-CLOGGING - Ability to handle solids in suspension or mixtures containing high percentage of solids
• SELF PRIMING - Can handle high percentage of air/gas/vapor with liquid
• VERSATILITY - Handles any fluid from clear water to highly viscous media
• REVERSIBLE - The rotation and direction of flow are reversible. This offers flexibility in handling variety of applications
